End2End Solutions

MEMS - Machine Efficiency Monitoring System

MEMS work on the principal of drawing electrical signals from a given machine and then decoding signals based on their nature for mapping state of the machine which in turn is used for monitoring efficiency.

The solutions comprise of the following layers

    1. Hardware
    2. Signal Mapping
    3. Data Interface

Hardware Feature Set :

motherboard
    mother board

    Signal Types

    The Board works on 3 Signal Types

    1. Digital Inputs
    2. Analog Inputs
    3. Output Signals

    Digital Inputs
    There are a total of 8 Digital Inputs in the board that can range from a minimum of 5 Volts and a maximum of 12 Volts. The inputs are mapped as

    Digital Inputs : D1 /D2 /D3/D4 /D5 /D6 /D7 /D8
    Analog Inputs : A1 /A2 /A3
    Output Signals : O1 /O2 /O3 /O4 /O5 /O6 /O7 /O8
